process parameters:

● suitable for lcd size is 5 '10.2' complete unilateral, multiple ics and bonding;

● the spacing of the pressure head can be adjusted freely, while the minimum spacing of 50mm, maximum bonding two ic;

● duplex, the platform does not move, the pressure head and the pressing platform heated to ensure temperature stability;

● the minimum distance of ic and glass 0.5mm;

● pressure head specifications: 30 * 5.0mm, according to customer requirements of production;

● the actual accuracy: ± 3μm;

● around the adjacent two pressure head center distance: 300mm;

● temperature range: rt-400 ° c;

● heating: temperature control;

● process cycle: 11 seconds / piece;

● air consumption: 0.4 cubic meters / minute;

● working pressure 0.4 ~ 0.6mpa;

● power supply: single phase 220v, 50hz, power 2000w;

● total weight: 250kg dimension: l890 * w840 * h1360 (720)
