process parameters :

● fog / fob / ogs for a 10-inch hot-pressing technology;

● on the mounted ccd imaging system, set the led light source;

● cylinder dual-rail platform and out;

● fpc lamination range: 6 ~~ 80mm;

● pitch value 60μm above, the actual accuracy of ± 8μm;

● the indenter specifications: 60 * 1.2mm, according to customer requirements change;

● two head center distance 300mm;

● teflon automatic tape device;

● heating: temperature control; temperature range: rt-400 ° c;

● process cycle: 26 seconds / slice.

● average production can 220pcs / hour or more;

● air consumption: 0.4 cubic meters / minute;

● working pressure 0.4 ~ 0.6mpa;

● power: 220v, 50hz, 800w;

● total weight: 180kg dimension: l800 * w840 * h1310 (720)
